价格:￥0.00/pcs
起订:5000pcs
供应:106744pcs

发送询价

MATERIAL



1. HOUSING MATERIAL : GLASS FILLED PLYESTER UL94V-0PBT、NYLON2. HOUSING COLOR : BLACK OR OTHERS3. ConTACT MATERIAL : PHOSPHOR BRonZE φ0.46mm4. PLATING: GOLD PLATING OVER NICKEL.GOLD PLATINGTHICKNESS Fu"



   SPECIFICATIONS

ELECTRICAL1. VOLTAGE RATING: 125 VAC RMS.2. CURRENT RATING: 1.0AMP3. ConTACT RESISTANCE: 30 MILLIOHMS MAX.4. INSULATION RESISTANCE : 500 MEGOHMS MIN＠500 VDC5. DIELECTRIC WITHSTANDING RESISTANCE: 1000 VAC RMS.50Hz 1MINUTEMECHANICAL1. DURABILITY : 750 CYCLES MIN2. PCB RETENTION PRE-SOLDER: 1 LB MINENVIRONMENTAL1. STORAGE :-40℃~80℃2. OPERATION: 0℃~70℃
